GAS DECK OVEN
THE PRODUCT HAS TWO SERIESDIFFERENT OPERATION PANELS ARE OPTIONAL
INSTRUMENT-CONTROLLED SERIES AND COMPUTER-CONTROLLED SERIES
Gas Deck Oven (Computer-controlled)
| Name | Model | Size and specification (mm) | Voltage | Power | Gas category | Gas pressure | Gas consumption | Weight | Temperature control range |
|---|---|---|---|---|---|---|---|---|---|
| Gas Deck Oven (one layer with two trays) (computer-controlled) | JMD-KXD1-2 | 1330 × 840 × 650 | 220V | 100W | LPG | 2.8KPA | 0.28KG/H | 102KG | 0–400℃ |
| Gas Deck Oven (two layers with four trays) (computer-controlled) | JMD-KXD2-4 | 1330 × 840 × 1355 | 220V | 200W | LPG | 2.8KPA | 0.58KG/H | 170KG | 0–400℃ |
| Gas Deck Oven (three layers with six trays) (computer-controlled) | JMD-KXD3-6 | 1330 × 840 × 1670 | 220V | 300W | LPG | 2.8KPA | 0.88KG/H | 230KG | 0–400℃ |
| Gas Deck Oven (three layers with nine trays) (computer-controlled) | JMD-KXD3-9 | 1750 × 840 × 1700 | 220V | 300W | LPG | 2.8KPA | 1.0KG/H | 288KG | 0–400℃ |
Gas Deck Oven (Instrument-controlled)
| Name | Model | Size and specification (mm) | Voltage | Power | Gas category | Gas pressure | Gas consumption | Weight | Temperature control range |
|---|---|---|---|---|---|---|---|---|---|
| Gas Deck Oven (one layer with two trays) (instrument-controlled) | JMD-KXD1-2A | 1330 × 840 × 650 | 220V | 100W | LPG | 2.8KPA | 0.28KG/H | 102KG | 0–400℃ |
| Gas Deck Oven (two layers with four trays) (instrument-controlled) | JMD-KXD2-4A | 1330 × 840 × 1355 | 220V | 200W | LPG | 2.8KPA | 0.58KG/H | 170KG | 0–400℃ |
| Gas Deck Oven (three layers with six trays) (instrument-controlled) | JMD-KXD3-6A | 1330 × 840 × 1670 | 220V | 300W | LPG | 2.8KPA | 0.88KG/H | 230KG | 0–400℃ |
| Gas Deck Oven (three layers with nine trays) (instrument-controlled) | JMD-KXD3-9A | 1750 × 840 × 1700 | 220V | 300W | LPG | 2.8KPA | 1.0KG/H | 288KG | 0–400℃ |
Note:
All dimensions do not include handles, chimneys, power switches and power cords (only including leather legs or wheels).
